Home - Products - OEM DVD & Deckless - FOR MAZDA Series - KD-9035 Stereo receiver bluetooth car stereo for Mazda 3 2010-2012

KD-9035 Stereo receiver bluetooth car stereo for Mazda 3 2010-2012

OS: ANDROID 10
Screen Type: LCD, Capacitive Touch Screen
Screen Size: 9“
Resolution: 1024*600
Warranty: 1 Year
Place of Origin: Guangdong, China
Brand Name: KLYDE
Model Number: KD-9035

Quote Now

KD-9035 Stereo receiver bluetooth car stereo for Mazda 3 2010-2012

Description

Advantage & Features

Benefits

Description

Dear Customers,

Here is KLYDE car radio / car stereo factory. Before order , pls send us your car dashboard picture , car year version ,and original car function like with original rear camera, with factory amplifier like JBL , Infinity etc, and then we will help you confirm if our product fits your car . if need OEM order , pls contact me to get details.

PX5 Android 10.0 System parameter
OS	Android 11 System	TFT drive IC	Rockchip PX5
CPU	Rockchip PX5, Cortex A53, Octa Core	Amplifer IC	TDA 7851
Main Frenqency	1.5GHz	Power supply	*450W**
RAM	SAMSUNG DDR3, 2GB/4GB	GPS	JUMPSTAR JS-U710
Flansh	16GB/32GB/64GB/128GB	WIFI	BL-8188-EU1
DSP	BU32107 built in	Easy Connect	Support
CarPlay Android Auto	Optional (built in)	EQ / Audio IC	ROM BD37033FV-ME2
4G network	Optional (built in)	MCU IC	STM8S207R8
Radio	NXP 6686	Power IC	RT7291A
Bluetooth	BC6 BT5.0 (RD210) internet connection by BT, 3 ways call,Phone power and signal display	Working Temperature	-20℃-+80℃
Parrot Blutooth	FC6000T9（optional）	DVR	USB Camera, Optional (external)
Touch Screen	Capacitive and multi-touch screen	DAB BOX	SHINWA DB-MF03
LCD Screen	Hanstar Screen	OBD	Optional (external)
Rear view	AHD rear view camera input	TPMS	Optional (external)
DAB	Optional (built in)	DVB-T(MPEG4)	Optional (built in)
		ISDB-T(Full SEG)	Optional (built in)

Multi-media ParametersRadio Parameters

Music Format: MP3、WMA、AAC、RM、LFAC etc

Frenqency Range FM：76.0MHz-108.0MHz

Video Format: MPEG-1/2/4、H264、H263、VC1、RV、RMVB、DivX、Sorenson SparK、Spark、VP8、AVS Stream…

Frenqency Range AM: 522KHz-1620KHz

Picture Format: JPG/BMP/JEPG/GIF/PNG

Country: China、Europe、Eastern、Europe、Russia、USA1、USA2、Japan

DVD Parameters

Amplifer Parameters

Video output range:1.0V-1.2V(75Ω）

Test Voltage: 13.8V

Compatible Disc: DVD/DIVX/MP4/MP3/MP2/VCD

Max output power: 4*50WGPS

Parameters WIFI

Parameters Operation system Android 10.0
System Power supply: Vcc_3.3V

Support Map: Android 10.0 Map

Suppoted Protocol/standard：IEEE802.11B/g/n compatible WLAN

Main Frenqency:1.5GHz
Interface type: USB2.0

Map Solution1024*600

Frequency: 2.4-2.484GHz

Modulation: OFDM/DBPSK/DQPSK/CCK

RF Power: 15dBM

Optional accessory:

Built-in Parrot BT: $30

Built-in wireless CarPlay+Android Auto: $15

4G LTE : $35

OBDⅡ: $10

DAB+ Box : $20

TMPS : $55

DVR camera : $13 Rear
view camera : $10

AHD 960P Camera : $13

DVB-T2 Box : $55

ISDB (Full Seg) Box : $60

DVB-T(MPEG4) Box : $60

Before buying the professionally made Bluetooth car stereo for your car, it is important to know what is it? A Bluetooth car stereo is an electronic device that is used for entertainment purposes and has many useful features other than entertainment. Whenever you buy a Bluetooth car stereo for your vehicle you just have to download the application from the android play store and run the program to get connect it with your vehicle. It is a wireless control system that helps you to get control and monitor many functions of your vehicle.

High-quality audio/video sounds:
GPS Navigation system:
Smartphone Connectivity:
Voice control feature:
Large Display Touch Screen:
Front and Back Camera
Parking Sensors
Bluetooth connectivity
Steering wheel support buttons
Multiple languages
Handsfree calling
Social media Bluetooth accessibility and much more.

KD-9035 Stereo receiver bluetooth car stereo for Mazda 3 2010-2012

Description

Dear Customers,

Optional accessory:

Advantage & Features

Benefits
