KD-1753 car radio stereo for VOLVO S60 2018 car dvd player audio car video
- OS: ANDROID 10
- Screen Type: IPS, LCD, Capacitive Touch Screen
- Screen Size: 9"
- Resolution: 1024*600
- Brand Name: KLYDE
- Model Number: KD-1753
- Certification: ce, FCC, RoHS
Description
Advantage & Features
Benefits
Description
| PX5 Android 10.0 System parameter | |||
| OS | Android 9.0/10.0 System | TFT drive IC | Rockchip PX5 |
| CPU | Rockchip PX5 ,Cortex A53, Octa Core | EQ / Audio IC | ROM BD37033FV-ME2 |
| Main Frenqency | 1.5GHz | MCU IC | STM8S207R8 |
| RAM | SAMSUNG DDR3 , 2GB/4GB | Power IC | RT7291A |
| Flansh | 16GB/32GB/64GB/128GB | AHD 1080P rear camera | support |
| DSP | BU32107 built in | Parrot BT | FC6000T9（optional） |
| Optional (built in) | |||
| 4G network | Optional (built in) | LCD Screen | Hanstar Screen |
| Radio | NXP 6686 | Amplifer IC | TDA 7851 |
| DAB BOX | SHINWA DB-MF03 | Working Temperature | -20℃-+80℃ |
| DAB | Optional (built in) | DVR | USB Camera, Optional (external) |
| GPS | JUMPSTAR JS-U710 | TPMS | Optional (external) |
| WIFI | BL-8188-EU1 | OBD | Optional (external) |
| Easy Connect | Support | Power supply | 4*50W |
| Rear view | AHD rear view camera input | DVB-T(MPEG4) | Optional (built in) |
| ISDB-T(Full SEG) | Optional (built in) | ||
Multi-media ParametersRadio Parameters
Music Format: MP3、WMA、AAC、RM、LFAC etc
Frenqency Range FM：76.0MHz-108.0MHz
Video Format: MPEG-1/2/4、H264、H263、VC1、RV、RMVB、DivX、Sorenson SparK、Spark、VP8、AVS Stream…
Frenqency Range AM: 522KHz-1620KHz
Picture Format : JPG/BMP/JEPG/GIF/PNG
Country: China、Europe、Eastern、Europe、Russia、USA1、USA2、Japan
DVD Parameters
Amplifer Parameters
Video output range:1.0V-1.2V(75Ω）
Test Voltage : 13.8V
Compatible Disc: DVD/DIVX/MP4/MP3/MP2/VCD
Max output power: 4*50WGPS
Parameters WIFI
Parameters Operation system Android 10.0
System Power supply: Vcc_3.3V
System Power supply: Vcc_3.3V
Support Map ：Android 10.0 Map
Suppoted Protocol/standard：IEEE802.11B/g/n compatible WLAN
Main Frenqency:1.5GHz
Interface type: USB2.0
Interface type: USB2.0
Map Solution1024*600
Frequency: 2.4-2.484GHz
Modulation: OFDM/DBPSK/DQPSK/CCK
RF Power: 15dBM
Optional accessory:
Built-in Parrot BT: $30
Built-in wireless CarPlay+Android Auto: $15
4G LTE : $35
OBDⅡ: $10
DAB+ Box : $20
TMPS : $55
DVR camera : $13 Rear
view camera : $10
view camera : $10
AHD 960P Camera : $13
DVB-T2 Box : $55
ISDB (Full Seg) Box : $60
DVB-T(MPEG4) Box : $60
